MIL-STD-1553 Reference Manual
67
Chapter 3 – System Functions
Description
[0]
[1]
Constant
Shared RAM Test error
(CMD area)
- Data Pattern Test
- Walking Bit Test
- Addressing Test
- Bus Test
7
1
2
3
4
API_BITE_ERR_SHARED_RAM_CMD
API_BITE_ERR_DATA_PATTERN
API_BITE_ERR_WALKING_BIT
API_BITE_ERR_ADDRESSING
API_BITE_ERR_BUS
Shared RAM Test error
(ACK area)
- Data Pattern Test
- Walking Bit Test
- Addressing Test
- Bus Test
8
1
2
3
4
API_BITE_ERR_SHARED_RAM_ACK
API_BITE_ERR_DATA_PATTERN
API_BITE_ERR_WALKING_BIT
API_BITE_ERR_ADDRESSING
API_BITE_ERR_BUS
Transfer Test error
BC Broadcast
- electrical wrap, Bus A
- electrical wrap, Bus B
- electrical wrap, Bus A,BM
- electrical wrap, Bus B,BM
- isol.coupling, Bus A,BM
- isol.coupling, Bus B,BM
BC-RT, RT-BC
- isol.coupling, Bus A+B, BM
RT-RT
- isol.coupling, Bus A,BM
- isol.coupling, Bus B,BM
Mode codes
- isol.coupling, Bus A,BM
- isol.coupling, Bus B,BM
BC Timeout
- isol.coupling, Bus A,BM
- isol.coupling, Bus B,BM
9
1
2
3
4
5
6
7
8
9
10
11
12
13
API_BITE_ERR_TRANSFER
API_BITE_ERR_BC_BROAD_ELECT_A
API_BITE_ERR_BC_BROAD_ELECT_B
API_BITE_ERR_BC_BROAD_ELECT_A_BM
API_BITE_ERR_BC_BROAD_ELECT_B_BM
API_BITE_ERR_BC_BROAD_ISOL_A_BM
API_BITE_ERR_BC_BROAD_ISOL_B_BM
API_BITE_ERR_BCRT_ISOL_AB_BM
API_BITE_ERR_RTRT_ISOL_A_BM
API_BITE_ERR_RTRT_ISOL_B_BM
API_BITE_ERR_MODE_ISOL_A_BM
API_BITE_ERR_MODE_ISOL_B_BM
API_BITE_ERR_BC_TIMEOUT_ISOL_A_BM
API_BITE_ERR_BC_TIMEOUT_ISOL_B_BM
Interrupt Test error
10
API_BITE_ERR_INTERRUPT
D/A Converter Test, Bus A
11
API_BITE_ERR_DA_CONV_BUSA
D/A Converter Test, Bus B
12
API_BITE_ERR_DA_CONV_BUSB
Timing Test error
LS BC Minor Framing
- Time 50ms
- Time 10ms
- Time 1ms
LS RT Response Time
LS Intermessage Gap
13
1
2
3
10
20
API_BITE_ERR_TIMING
API_BITE_ERR_TIMING_MFRM_50
API_BITE_ERR_TIMING_MFRM_10
API_BITE_ERR_TIMING_MFRM_1
API_BITE_ERR_TIMING_RT_RESPONSE
API_BITE_ERR_TIMING_IMG
