MIL-STD-1553 Reference Manual
68
Chapter 3 – System Functions
Description
[0]
[1]
Constant
HS Internal Selftest error
Memory Tests
- Addressing Test
- Pattern Test 0x5555
- Pattern Test 0xAAAA
- Pattern Test 0xFFFF
- Pattern Test 0x0000
- Walking Zero Test
- Walking One Test
PBI Test
- Wrong PBI ID Code
Loop Tests
- Simulator Transfer
Count mismatch
- Simulator Error Count
mismatch
- Monitor Activity Transfer
Count mismatch
- Monitor Activity Transfer
Error mismatch
- Simulator BC to RT data
mismatch
- Simulator RT to BC data
mismatch
- Monitor data mismatch
- Monitor Transfer Count
mismatch during Replay
Test
- Monitor Error Count
mismatch during Replay
Test
- Monitor data mismatch
during Replay Test
Timetag Counter Tests
- Time Tag too slow
- Time Tag too fast
- Time Tag Timeout
(not counting or very
slow)
101
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
40
41
42
API_BITE_ERR_HS_INTERN_SELFTEST
API_BITE_ERR_HS_INT_ADDR
API_BITE_ERR_HS_INT_PAT_55
API_BITE_ERR_HS_INT_PAT_AA
API_BITE_ERR_HS_INT_PAT_FF
API_BITE_ERR_HS_INT_PAT_00
API_BITE_ERR_HS_INT_WALK_0
API_BITE_ERR_HS_INT_WALK_1
API_BITE_ERR_HS_INT_WRONG_PBI
API_BITE_ERR_HS_INT_SIM_TX_CNT
API_BITE_ERR_HS_INT_SIM_ERR_CNT
API_BITE_ERR_HS_INT_MON_TX_CNT
API_BITE_ERR_HS_INT_MON_ERR_CNT
API_BITE_ERR_HS_INT_SIM_BCRT
API_BITE_ERR_HS_INT_SIM_RTBC
API_BITE_ERR_HS_INT_MON_DATA
API_BITE_ERR_HS_INT_MON_TX_CNT_REP
API_BITE_ERR_HS_INT_MON_ERR_CNT_RE
P
API_BITE_ERR_HS_INT_MON_DATA_REP
API_BITE_ERR_HS_INT_TT_SLOW
API_BITE_ERR_HS_INT_TT_FAST
API_BITE_ERR_HS_INT_TT_TIMEOUT
