4.2 – Icons
Thanks to the wide number of icons available on its display, the dash-logger shows a good amount of information. Here follows
explanation of their meaning and working mode.
Water Temperature
It turns on when water temperature gets over a customized value (default value 105°C)
Battery
It turns on when
battery voltage gets under a customized value (default value 10V)
Oil pressure
It turns on when the bike engine detects a problem with oil pressure.
Traction control (S-KTRC)
Working range: 0 (OFF)-5 (Max)
Power Mode
Working range: Low-Middle-Full
Launch Control Level
Working range: from 1 (min) to 3 (max)
Electronic suspensions (KECS)
Working modes: Manual, Road and Track
Engine Brake (KEBC)
Available options: Low, OFF
Intelligent Braking System (KIBS)
Available Levels: ON, FRONT/REAR, OFF
Quick Shift
Available levels: Up (shown here on the left), Down, Up&Down, OFF
Economy
It turns ON when: RPM is lower than 6500 and throttle position is <5%
REC
It turns on when the dash-logger is recording.
