Aim SC808 - Xear Audio Center Interface Elements; Audio Status Panel Description

HD Audio PCI-e V2.0
27
AudioStatusPanel


1.Playback(SpeakersOut)
ItindicatesthatSpeakeristheoutputdefaultdevice.

2.Capture(DesktopMic)
ItindicatesthatDesktopMicistheinputdefaultdevice.

3.SpeakerNumbers(2/4/5.1/7.1)
Itindicatesthespeakernumbers(forSpeakerdeviceonly).

4.SampleRate
ItindicatesthePlaybacksampleratefordefaultoutputdevice.

 5.AudioOutputeffectindicator
Itindicatestheplaybacksoundeffectstatus.
Abbreviation Soundeffect
EQ Equalizer
EM EnvironmentEffects
VSS 7.1VirtualSpeakerShifter
FB FlexBassII
KS XearSingFXKeyShifting
VF XearSingFXVocalFading
XS XearSurroundSpeaker
AB XearAudioBrilliant
DB XearDynamicBass
SVN XearSmartVolume
VC XearVoiceClarity
SMX XearSurroundMax

3
4
5
6
7
1
2
