HD Audio PCI-e V2.0

VolumecontrolPage

 FunctionIntroduction

ThisfunctionpageprovidesavolumecontrolforHeadphone

device.



1. Volumecontrolbar:

Headphone‐ItcanadjustvolumelevelforHeadphonedevice

.

2. Left/RightChannelLock:

Clickingonthelock/un‐lockbutton,itcanlockleft‐channeland

right‐channeltosyncL/Rchannel.



3. Mute/Un‐mute:

Clickingonthemute/un‐mutebutton,itcanmuteallchannels.



4. dBInputArea:

Youcandirectlyfill‐inadBvalueintothistextboxtosetthe

volumelevel

..

1

4

2
