Aim SC808 - Speaker Configuration and Testing

HD Audio PCI-e V2.0
32
SpeakerSettingPage


 FunctionIntroduction
Youcansetthespeakernumbers(Stereo/Quadraphonic/5 . 1 
Surround/7. 1Surround)inthispage.

1. LFE/CenterChannelSwap‐‐Whenthisitemenable,itcanswap
theaudiostreambetweenCenter/LFE.

2. SpeakerTest–Clickthe“SpeakerTest ”button,theCPLwillauto
playtestsoundinorder.
Front‐Left>Front‐Right>Back‐Left>Back‐Right>Center>Bass

NOTE:DuetoStereoMusicmodehastwochannelsoutputonly,this
featureisdisappearfromthepopmenuofsecondspeakers.
1
2
