Aim SC808 - Speaker Volume Control and Muting

HD Audio PCI-e V2.0
31
VolumecontrolPage


 FunctionIntroduction
ThisfunctionpageprovidesavolumecontrolforSpeakerdevice.

1. Volumecontr olbar:
Master–Itcanadjustvolumelevelforallchannels.
Front‐Itcanadjustvolumelevelforfrontchannel.
2. Left/RightChannelLock(Front,Cen/LFE,Rear,Side):
Clickingonthelock/un‐lockbuttoncansyncleft‐channeland
right‐channel.
3. Mute/Un‐mute:
Clickingonthemute/un‐mutebuttoncanmuteallchannels.
4. dBInputArea(Front,Cen/LFE,Rear,Side):
Youcandirectlyfill‐inadBvalueintothistextboxtosetthe
volumelevel.
1
3
2
4
