HD Audio PCI-e V2.0

VolumecontrolPage



 FunctionIntroduction

Thisfunctionpageprovidestherecordingvolumeandthevolume

controlofMicrophonedevice.



1. Volumecontrolbar:

Mic‐In–Itcanadjustthevolumelevelofrecording.

2. Left/RightChannelLock:

Clickingonthe Lock/ Un‐Lockbutton can syncthe left‐channel

andright‐channelvolume.



3. Mute/Un‐mute:

ClickingontheMute/Un‐Mutebuttoncanmuteallchannels.

4. dBInputArea

Youcandirectlyfill‐inadBvalueintothistextboxtosetthe

volumelevel.

1

2

3

4
