HD Audio PCI-e V2.0
52
Equal izer
 FunctionIntroduction
Itprovidesa10‐bandEQfunction;youwillabletoadjustthe EQ
bandbymanualandcreatecustomizepresetitemsorclickonthe
presetEQmode.

1. EQenable/disableswitch
Clickonthischeckboxtoenable/disable EQ

2. Presetmode
Selectapre‐setmodeforequalizerthatisdesignedaccordingly.
Thereare12presetmodessuchasBass,Treble,Live,Rock,Jazz,
etc.

3. EQbandcontroller
Youcanchangethegainsettingforeachband
(30/60/120/250/500/1K/2K/4K/8K/16K)

4. Manualmode
Youcanchangethegain
valueofeachbandandthengiveita
nametothe“A.InputField”andthenclick“
”tosaveyour
1
3
2
4
