Aim SC808 - SPDIF-Out Volume Control and Muting

HD Audio PCI-e V2.0
62
VolumecontrolPage


 FunctionIntroduction
ThisfunctionpageprovidesavolumecontrolforSPDIF‐Outdevice.

1. Volumecontrolbar:
SPDIF‐Out–Youcanusethisbartoincrease/decreasevolume
level.
2. Left/RightChannelLock:
ClickingontheLock/Un‐Lockbuttoncansynctheleft‐channel
andright‐channelvolume.
3. Mute/Un‐mute:
Clickingonthemute/un‐mutebuttoncanmuteSPDIF‐Out.
4. dBInputArea:
Youcandirectlyfill‐inadBvalueintothistextboxtosetthe
volumelevel.
1
2
3
4
