Aiphone GT SYSTEM User Manual

- 11 -
Mounting parts
Combination examples
4-module front
frame
GT-4F
Mounting bracket
(included with
GT-4F)
Screws
3-module front
frame
GF-3F
Mounting bracket
(included with
GF-3F)
2-module front
frame
GF-2F
Mounting bracket
(included with GF-2F)
4-module back box
GT-4B
3-module back box
GF-3B
2-module back
box
GF-2B
Joint pipe
Mounting gauge
Rain hood
GT-nH
Surface-mount box
GF-nBA
Hooded surface-
mount box
GT-nHB
80 cm (32") connection cable
GF-C
* A number appears in place of n.
GT-DP-L/GT-DP+
GT-DA-L/GT-DA
GF-4P+GT-SW
GF-BP
GF-4P+GT-SW
GT-DP-L/GT-DP+
GT-DA-L/GT-DA
GT-VP+GT-VA
2
B
A
C
3
E
D
F
5
K
J
L
8
U
T
V
4
H
G
I
6
N
M
O
1
0
9
Y
X
W
Z
7
R
Q
P
S
GT-DP-L/GT-DP+
GT-DA-L/GT-DA
GT-NS-V/GT-NS+
GT-NSP-L
GF-10KP+
GT-10K
2
B
A
C
3
E
D
F
5
K
J
L
8
U
T
V
4
H
G
I
6
N
M
O
1
0
9
Y
X
W
Z
7
R
Q
P
S
GT-DP-L/GT-DP+
GT-DA-L/GT-DA
GT-VP+GT-VA
GT-NS-V/GT-NS+
GT-NSP-L
GF-10KP+
GT-10K
Audio only, Direct select type (8 stations)
Audio only, 10 key type
Audio/video, Direct select type (8 stations)
Audio/video, 10 key type

Aiphone GT SYSTEM Specifications

General

Wiring	2-wire
Door Release	Yes
Operating Voltage	24V DC
Wire Gauge	18 AWG
Type	Intercom System
Power Source	24V DC
Installation	Surface-mounted
Communication	Hands-free
Expandability	Expandable to multiple door stations and master stations
Mounting	Wall-mount
Operating Temperature	14°F to 140°F (-10°C to 60°C)
Humidity Range	10% to 90% (non-condensing)
Frequency Response	300 Hz to 3.4 kHz
Maximum Stations	500
Maximum Door Stations	32 door stations
