Airwell Multi Split DUO 50 DCI - Page 10

2-5
PRODUCT DATA SHEET
SM DUODCI 1-A.1 GB
2.2.7 BS 12 DCI Specifications
Model Indoor Unit / Type BS 12 DCI
Installation Method FLARE
Fan Motor Output W 36
Power Supply V/Ph/Hz 220-240 / 1/ 50
INDOOR
Fan Type & Quantity Centifugal *2
Airflow
(2)
Cooling / Heating
H/M/L m
3
/hr 830 700 530
Sound Power Level
(3)
Cooling / Heating
L - H dB (A) 52-59
Sound Pressure Level
(4)
Cooling / Heating
L - H dB (A) 35-42
Condensate Drain Tube I.D. mm 16
Dimensions W/H/D mm 860 245 680
Weight Kg 30.0
PacKage Dimensions W/H/D mm 1055 305 728
StacKing Height Units 6
Heating Elements KW N/A
Moisture Removal L/hr 1.3
NOTE:
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
CONTENT
