7-1
ELECTRICAL DATA
SM DUODCI 1-A.1 GB
7. ELECTRICAL DATA
Power Supply 1 PH, 220-240 VAC, 50Hz
Connected to Outdoor
Maximum Current 13.7 A
Inrush Current 35 A
Starting Current 10 A
Circuit breaKer 16 A
Power supply wiring - No. x cross section 3 X 2.5 mm
2
Interconnecting cable - No. x cross section 2 X 4 X 1.5 mm
2
Note:
• Inrush current is the current when power is up. (charging the DC capacitors at outdoor unit
controller).
• Starting current is the current when starting the compressor
NOTE
Power wiring cord should comply with local lows and electrical
regulations requirements.
