Airwell Multi Split DUO 50 DCI User Manual

2-1
PRODUCT DATA SHEET
SM DUODCI 1-A.1 GB
2. PRODUCT DATA SHEET
2.1 Outdoor Unit DUO 50 DCI Specifications.
Model DUO-50 DCI R410A
Function Cooling Heating
Capacity
(1)
Kcal/hr 4300(1030~5570) 5330(820~6670)
Btu/hr 17050(4090~22100) 21140(3240~26430)
W 5000(1200~6480) 6200(950~7750)
Total Input
(1)
W 1470(420~2160) 1670(375~2050)
E.E.R (Cooling) / C.O.P (Heating)
(1)
W/W 3.4 3.71
Running Current A 6.7 7.7
Starting Current A 10.5
Inrush Current A 35
Power Supply V/Ph/Hz 230V/ 1PH / 50Hz
OUTDOOR UNIT
Refrigerant control Electronic expansion valve
Compressor type Scroll DC Inverter
Model Panasonic 5CS130XCC03
Starter type ---
Protection device Outdoor SW control
Heat exchanger Hydrophilic flat fin ,Grooved tube coil
Fan (drive) x No. Propeller x 1
Airflow m
3
/hr 2160
Motor output W 40
Defrost method Reverse cycle
Noise level Pressure
(4)
dB(A)
52 53
Power 62 63
Dimensions W*D*H mm 795*290*610
Weight Kg 43
PacKing
dimensions
W*D*H mm 945 * 395 * 655
Unit stacKing units 3
TUBING
Refrigerant R410A
Charge(7.5m connection tube) Kg 1500
Fresh Air NO
Tube size liquid mm 6.35
O.D. suction mm 9.53
Connection
method between
the indoor and
outdoor units
indoor & outdoor Flared
height difference
between indoor units
Max.5m
height difference
between indoor &
outdoor
Max.10m
tubing length
Standard 7.5m
Max.25m for one unit and 30m for total
additional charge No need
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
