Airwell Multi Split DUO 50 DCI User Manual

2-6
PRODUCT DATA SHEET
SM DUODCI 1-A.1 GB
2.3 Data For Outdoor Unit DUO 50 DCI Combinations
(Based on FLO)
Indoor Units
Combinations
Cooling Heating
Room A Room B
Total
Capacity
Power Input Room A Room B
Total
Capacity
Power Input
[W] [W] [W] [W] [W] [W] [W] [W]
25
2500 -
2500
(1220 - 3700)
680
(420 - 980)
3400 -
3400
(950 - 4000)
1135
(375 - 1250)
35
3500 -
3500
(1220 - 4350)
1030
(420 - 1275)
4200 -
4200
(950 - 5200)
1575
(375 - 1760)
25+25
2500 2500
5000
(1400 - 6000)
1470
(410 - 2100)
3100 3100
6200
(1250 - 7100)
1670
(320 - 1960)
25+35
2500 3000
5500
(1400 - 6240)
1850
(410 - 2130)
3100 3450
6550
(1250 - 7400)
1760
(320 - 2020)
35+35
3000 3000
6000
(1400 - 6480)
2040
(410 - 2160)
3450 3450
6900
(1250 - 7750)
1970
(320 - 2050)
2.3.1 Correction Factors:
Capacity Power input
Model
Cooling Heating Cooling Heating
SX25 DCI
1.0 0.95 1.0 1.08
SX35 DCI
1.02 0.96 1.0 1.08
BS35 DCI
1.02 0.95 1.0 0.91
K25 DCI
1.02 1.01 1.01 1.01
K35 DCI
1.06 0.97 1.05 0.99
2.3.2 Calculation Example.
FLO25+K35 Cooling Mode:
Indoor Unit Cooling Capacity [W] Power Input [W]
Room A – FLO25 2500 1850 x (2500/5000) = 840
Room B – K35 (3000 x 1.06) = 3180 1850 x (3000/5000) x 1.05 = 1059
Total (2500+3180) = 5680 840+1059 = 1899
2.3.3 K35+K35 Heating Mode:
Indoor Unit Heating Capacity [W] Power Input [W]
Room A – K35 (3000 x 0.97) = 2910 (2040 x 0.99) = 2019
Room B – K35 (3000 x 0.97) = 2910 (2040 x 0.99) = 2019
Total (2910+2910) = 5820 (2019+2019) = 4038
