Airwell Multi Split DUO 50 DCI - Page 61

13-2
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DUODCI 1-A.1 GB
14.2 Outdoor Unit: DUO 50 DCI
No. Part No. Description Unit
1 433218
Front panel A
1
2 4526340
Air inlet ring-420
1
3 433223
Painting insulation plate
1
4 4526476
Axial fan OD=401
1
5 4526475
DC motor ARW 44 8p 40W
1
6 4526457
Motor support
1
7 4526482
Base painting assy
1
8 4526456 Partition 1
9 4526203
Outdoor DCI controller (English) (EHK P/N:906-097-00)
1
10 4526295 MSMP electronic box 1
11 4526227 MSMP communication board (EHK P/N:901-002-00) 1
12 4526224
EMI filter board (EHK P/N:901-098-00)
1
13
452823600 Therminal sheet assy.
1
14 4526220 Fuse stand JEF-511B (EHK P/N:105-038-00) 1
15 4527130
8 Poles terminal block
1
16 4526533
Fuse 65TS(25A,230V)
1
17 4526314
MSMP communication wire
1
18 4526396 Choke assy 1
19 204107 Cable clip 3
20 4526225 Power lead line 1
21 4526968 Grounding wire with magnetic ring 1
22 4526223 AC-IN wire 1
23 4526222 Fuse connected wire 1
24 4526226 Power connection wire 1
25 4526221
Compressor wire
1
26 433230 Valve cover 1
27 452630201 Gas valve for R410A 1
28 452630200 Gas valve for R410A 1
29 4526301 Liquid valve 2
30 4526827 Electronic expansion valve CAM-BD15 FKS-1 2
31 452682800 EEV coil (red) CAM-MD12FKS-1 1
32 452682802 EEV coil (white) CAM-MD12FKS-2 1
33 4526430 Valve support (painting plate) 1
34 4526429
Right side panel (painting plate)
1
35 4523446
Compressor assy 5CS130XCC03
1
36 452813100
Accumulator assy.
1
37 433228
Back side net
1
38 4526775
Compressor top thermistor (CTT)
1
39
4526459 Condenser soldering assy
1
40 4526298
Bridge
1
41 4522509
4-way valve coil
1
42 4526471
4-way valve soldering assy
1
43 4518952 4-way valve 1
44 4526969
Suction tube thermistor 1 (SUT1)
1
45 4526774
Outside air thermistor (OAT)
1
46 4526776
Outside coil thermistor (OCT)
1
47 4526970
Suction tube thermistor 2 (SUT2)
1
48 452911100
Suction tube thermistor 3 (SUT3)
1
49 4519614
Painting top cover
1
50 4526480
Gasket for axial fan
1
51 4519300
Nut M5 L
1
52 433225
Handle
1
53 4519607
Left side panel (painting plate)
1
