FS-HDR Frame Synchronizer/Converter/HDR-WCG Processor v1.0r1 55 www.aja.com
NOTE: The STATUS menu always shows the FS-HDR’s current Ethernet settings. The
parameters shown on the CONFIG Menu Group IP configuration menu may not
display the values the unit is currently using.
Vid 1/2 I/O
(4Ch only) This menu shows the current primary video settings for Video
Processors 1 and 2.
IN1 Input Source Format
OUT1 Output Source Format
IN2 Input Source Format
OUT2 Output Source Format
Selected (physical) video 1 input & detected format.
Selected video output 1 format & selected audio input
used on output.
Selected (physical) video 2 input & detected format.
Selected video output 2 format & selected audio input
used on output.
Vid 3/4 I/O
(4Ch only) Same as Vid 1/2 I/O status menu, except for Video Processors 3 and 4.
Vid I/O
(SingleCh only) This menu shows the current primary video settings for Video
Processor.
IN Input Source(s) Format
GEN Genlock Source Status
OUT Format AudIn
Vid CC Status
Selected (physical) video 1-4 inputs & detected format.
Selected Genlock source and format.
Selected video output format & selected audio input
used on output
Closed Caption status
Vid 1 Format
(4Ch only) This menu shows the current primary video settings for Video
Processor 1.
IN1 Input Source Format
BKGD Backgd Source
GEN Genlock Source Format
OUT1 Format
Selected video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected video output format.
Vid 2-4 Format
(4Ch only) Same as Vid 1 Format menu, except for Video Processors 2-4.
Vid 1 Alarm
(4Ch only) This menu shows the Video Processor 1 alarm status. Absence of alarm
shows as OK. If selections are incompatible, the status of the affected signal
shows Incompat.
IN1 Input Source Status
BKGD Backgd Source Status
GEN Genlock Source Status
Rate Status
Video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
System Output Frame Rate (59/29/23.98, 50/25, 60/30/24)
Vid 2-4 Alarm
(4Ch only) Same as Vid 1 Alarm menu, except for Video Processors 2-4.
