When set to Mix Down
• The stereo output of the Mix Down Module is routed to audio channels 1 and
2 of the SDI output. The other channels are muted.
When set to Sig Gen 1KHz, Sig Gen 400Hz or Mute:
• The selected source (tone or silence) is routed to every output channel.
When set to Map:
• The mapped source is routed to each output channel according to the last
congured mapped source for each channel in the output.
• The following channel map menus become available via the SELECT knob.
1.1-1.16 SDI1 Output Channel
When Map is selected, each listed source can be mapped to each output channel
of the currently selected output menu.
SDI1 Output Ch 1
through
SDI1 Output Ch 16
Select the source to route to the selected output from the following:
-SDI1-8 Ch 1 - Ch 16
-AES Ch 1-16
-MADI BNC 1-64
-MADI Fiber 1-64
-Mix Down 1 L
-Mix Down 1 R
-Mix Down 2 L (4Ch only)
-Mix Down 2 R (4Ch only)
-Sig Gen 1kHz
-Sig Gen 400Hz
-Mute
2.0-4.0 SDI2-4 Audio Out
See "1.0 Vid 1 Audio Out" on page 95
