AJA FS-HDR - Factory Preset; 1.40 Presets #1-#40; Video with Audio Routing; Interaction of Presets and Gpis

FS-HDR Frame Synchronizer/Converter/HDR-WCG Processor v1.0r1 71 www.aja.com
Caution! In Four Channel Mode, each Preset saves all the settings for all four
channels. Storing and recalling a Preset will aect all the settings for all
four channels in that mode. Care must be taken to establish a policy for
the use of FS-HDR Presets, especially if the FS-HDR is operated in Four
Channel mode and the dierent channels have dierent users..
During recall, the display reads, Recalling until the recall is finished. On recall
completion, the displays shows the success or failure: Recalled, Failed, or Empty.
A failed or empty recall does not recall anything and leaves the FS-HDR as it was.
(Preset registers are empty until you store something in them.)
During a store, the display reads Storing until the store is finished. On store
completion, the display shows Complete or Failed. A failed store does not store
anything and leaves the preset register as it was. To retry a failed store, turn
SELECT to another preset number and then back to the desired preset number.
1 Factory Preset
This parameter recalls a read-only Factory Preset.
Factory
Recall
Recalls factory values for all System, Video, Audio, and most Cong
parameters. Push ADJUST for four seconds to perform the recall.
The display reports “Factory values” during the recall. User
preferences, network settings, and existing Presets are not
aected by recalling the Factory Preset.
1.1-1.40 Presets #1-#40
These parameters let you recall, edit the name of, and store an FS-HDR preset
configuration for the selected storage register. Forty storage registers are
available.
Preset #1–#40
[Preset Name]
Recall
Edit Name
Store
Shows the currently selected preset register number. Turn SELECT
choose the desired register. Then turn ADJUST to choose Recall,
Edit Name, or Store for the selected register.
Shows the name of the selected preset register, which can be
edited.
Recalls that preset. Push ADJUST momentarily to perform (take) the
recall. The display reports “Loading” and “Complete” during the
recall.
Enables editing the name of the preset register. Push ADJUST to
enable editing (blinking character), use the SELECT and ADJUST
knobs to edit the name and then press ADJUST to save the edited
preset register name.
Stores the current set of all System, Video, Audio, and most Cong
parameters to the selected preset register.
Video with Audio Routing
Presets can be used to coordinate audio and video routing. Store and name
presets that match the desired audio inputs to each desired video input, and use
those presets to select the video inputs, causing the configured audio to follow.
Interaction of Presets and GPIs
Triggering presets using GPI inputs offers considerable power but also requires
some care to avoid unexpected results. If you plan to trigger presets using GPIs,
please see the information about the "Interaction of Presets and GPIs" on page 59.
