2.1-2.8 SDI 1-8 SRC Mode
These parameters control the use of sample rate converters for the incoming SDI
embedded audio. This setting affects all 16 embedded audio channels for that
SDI input, if present.
Auto (default)
On
O
The system decides how to handle sample rate conversion. PCM uses
SRC, compressed data doesn’t use SRC.
Sample rate conversion is always performed on the inputs.
Sample rate conversion is never performed on the inputs.
In Auto mode, normal PCM audio passes through the Sample Rate Converters and
gets converted, as appropriate. If any of the active input signals are non-PCM the
SRC is turned off for all audio inputs.
2.9 AES SRC Mode
These parameters control the use of sample rate converters for the incoming AES
audio. This setting affects all 16 AES input channels.
Auto (default)
On
O
The system decides how to handle sample rate conversion. PCM uses
SRC, compressed data doesn’t use SRC.
Sample rate conversion is always performed on the inputs.
Sample rate conversion is never performed on the inputs.
NOTE: For SRC, all AES channels must be synchronous to AES1 (channel pair 1&2), or to
the lowest numbered AES pair if AES1 is not present.
2.10 MADI BNC SRC Mode
These parameters control the use of sample rate converters for the incoming
MADI BCN audio. This setting affects all 64 MADI BNC input channels
Auto (default)
On
O
The system decides how to handle sample rate conversion. PCM uses
SRC, compressed data doesn’t use SRC.
Sample rate conversion is always performed on the inputs.
Sample rate conversion is never performed on the inputs.
In Auto mode, normal PCM audio passes through the Sample Rate Converters and
gets converted, as appropriate. If any of the active input signals are non-PCM the
SRC is turned off for all audio inputs.
2.11 MADI Fiber SRC Mode
These parameters control the use of sample rate converters for the incoming
MADI Fiber audio. This setting affects all 64 MADI Fiber input channels
Auto (default)
On
O
The system decides how to handle sample rate conversion. PCM uses
SRC, compressed data doesn’t use SRC.
Sample rate conversion is always performed on the inputs.
Sample rate conversion is never performed on the inputs.
In Auto mode, normal PCM audio passes through the Sample Rate Converters and
gets converted, as appropriate. If any of the active signal pairs are non-PCM the
SRC is turned off for all audio inputs.
