FS-HDR Frame Synchronizer/Converter/HDR-WCG Processor v1.0r1 63 www.aja.com
NOTE: To eliminate trailing characters to shorten an existing system name, overwrite
them with a hyphen (-) or space.
2 FS-HDR Mode
Selects whether the FS-HDR will operate in Four Channel or Single Channel mode.
Pressing the ADJUST knob at the “Change Mode?” prompt will reboot the FS-HDR
in the other operating mode. During reboot, the display shows [Rebooting], goes
dark momentarily, and then shows the percentage of progress as the system
reboots. Reboot should take no longer than 90 seconds. This parameter has no
default setting (is only be used to change to the other mode) and is not saved in
Presets.
HD/SD
4K/UHD
After reboot the FS-HDR will operate in Four Channel (HD/SD) mode.
After reboot the FS-HDR will operate in Single Channel (4K/UHD) mode.
3.1 IP Config
This parameter determines the type of TCP/IP network configuration used by the
FS-HDR. Consult your network administrator about how to set this value.
DHCP (default)
Static Addr
Select automatic IP address assignment from the LAN DHCP server. If the
FS-HDR cannot nd a DHCP server, it fails over to the static IP address.
Assign a static IP address manually (using the following parameter
menus). The FS-HDR factory default static IP address is 192.168.0.2.
3.2 IP Address
This parameter determines the static IP address used by the FS-HDR for TCP/IP
networking. Consult your network administrator about how to set this value.
IP Address variable If IP Cong is set to DHCP dynamic addressing (default), the IP Address is set
automatically by the network’s DHCP server.
If IP Cong is set to Static Addr, manually enter an IP address.
If IP Cong is set to DHCP and there is a DHCP failure, the IP address is set to
the static IP address. The factory default static IP address is 192.168.0.2.
Octet Value Entry Procedure
Set the octets (numbers between periods) values as follows:
1. Push ADJUST momentarily to enter edit mode.
2. Turn SELECT to select the octet you want to edit, indicated by blinking.
3. Turn ADJUST to enter the new value.
• If you need to revert to the previous setting (undo changes), push SELECT.
4. Push ADJUST momentarily to save and activate the new setting.
• If you want to revert to the default value, hold down ADJUST for 4 seconds.
