Vid Alarm
(Single Ch only) This menu shows the Video Processor 1 alarm status. Absence of
alarm shows as OK. If selections are incompatible, the status of the affected signal
shows Incompat.
IN Input Source(s) Status
GEN Genlock Source Status
Rate Status
Video input source alarm status.
Selected Genlock source alarm status.
System Output Frame Rate (59/29/23.98, 50/25, 60/30/24)
SDI Input
This menu shows the status of all eight SDI inputs.
SDI1 Status SDI5 Status
SDI2 Status SDI6 Status
SDI3 Status SDI7 Status
SDI4 Status SDI8 Status
Statuses for SDI inputs 1-8: (Format, No Input, No SFP)
Monitor Output
This menu shows the status of the monitor outputs (BNC and HDMI).
Monit Status
Fmt Status
Crop Status
Output selected for monitoring (Vid1-4 Out)
Output format.
Crop status (O, On).
AES Input
This menu shows the status of all eight AES channel pair inputs. Each can carry a
stereo digital audio signal.
AES1 Status AES5 Status
AES2 Status AES6 Status
AES3 Status AES7 Status
AES4 Status AES8 Status
Statuses for AES inputs 1-8: (Present, No Input)
MADI In/Out
This menu shows the status of the MADI audio inputs and outputs.
BNC In Mode Status
BNC Out Mode
Fib In Mode Status
Fib Out Mode
BNC input mode (56ch, 64ch), status (Present, No Input)
BNC output mode
Fiber input mode, status
Fiber output mode.
Power/Temp Alarm
This menu shows the power supply status of the FS-HDR and the temperature
status. If a power supply is unplugged, the display indicates PS OFF or PS Error.
PS1 Alarm Status
PS2 Alarm Status
TmpAlarm Status
Displays the state of the PS1 power supply (OK or ERROR).
Displays the state of the PS 2 power supply (OK or ERROR).
Displays a temperature alarm if the FS-HDR overheats.
