2 Output Timing V
When adjusting the vertical timing (V), this parameter specifies a number of lines
to offset, moving the screen up to a half a frame up or down.
Variable Adjustment range increments from half a frame up to a half a frame
down in single line increments. The maximum varies, depending
on the format already chosen. Default: 0
Output Timing Memory
Independent horizontal and vertical timing values are kept for all available output
formats.
Output Timing Ranges
The table below lists the output timing ranges for various video frame rates.
Table 8. Output Timing Ranges
Output Frame Rate
Horizontal Vertical
Min Max Min Max
UHD23.98 0 2749 -562 562
UHD24 0 2749 -562 562
UHD25 0 2639 -562 562
UHD29.97 0 2199 -562 562
UHD50 0 2639 -562 562
UHD59.94 0 2199 -562 562
4K1080p23.98 0 2749 -562 562
4K1080p24 0 2749 -562 562
4K1080p25 0 2639 -562 562
4K1080p29.97 0 2199 -562 562
4K1080p50 0 2639 -562 562
4K1080p59.94 0 2199 -562 562
1080i50 0 2639 -562 562
1080i59.94, 1080i60 0 2199 -562 562
1080p23.98, 1080p24 0 2749 -562 562
1080p25 0 2639 -562 562
1080p29.97, 1080p30 0 2199 -562 562
1080p50 0 2639 -562 562
1080p59.94, 1080p60 0 2199 -562 562
1080psf23.98, 1080psf24 0 2749 -562 562
1080psf25 0 2639 -562 562
1080psf29.97, 1080psf30 0 2199 -562 562
2Kx1080p23.98, 2Kx1080p24 0 2749 -562 562
2Kx1080p25 0 2639 -562 562
2Kx1080p29.97, 2Kx1080p30 0 2199 -562 562
2Kx1080p50 0 2639 -562 562
2Kx1080p59.94, 2Kx1080p60 0 2199 -562 562
525i59.94, 525psf29.97 0 857 -262 262
625i50, 625psf25 0 863 -312 312
720p23.98, 720p24 0 4124 -375 375
