Appendix A: Specifications
Video Input/Output Formats
The FS1-X supports a wide variety of video formats and connectors, as listed below.
Format Exceptions The following formats are not supported:
• 720p/23.98/24/25/29.97
• All 30/60 frame rates
• 4:4:4 YCbCr, RGB, or XYZ inputs
• 4:2:2 YCbCr 12-bit inputs
SDI and Fiber The FS1-X has two standard SDI video inputs and outputs, and two optional Fiber video
inputs and outputs.
All SDI video inputs and outputs, including Fiber, are YCbCr 4:2:2 pixel format.
SD-SDI, 270Mb
(SMPTE 259-C)
• 525i/59.94
• 625i/50
HD-SDI, 1.4835 Gb
(SMPTE 292)
• 720p/59.94
• 1080i/59.94
• 1080PsF/23.98, 1080PsF/29.97
• 1080p/23.98, 1080p/29.97
• 2Kx1080p/23.98, 2Kx1080p/29.97
HD-SDI, 1.485 Gb
(SMPTE 292)
• 720p/50
• 1080PsF/24, 1080PsF/25
• 1080p/24, 1080p/25
• 2Kx1080p/24, 2Kx1080p/25
Dual-link HD-SDI, 2x
1.4835Gb (SMPTE 372)
• 1080p/59.94
• 2Kx1080p/59.94
Dual-link HD-SDI, 2x
1.485Gb (SMPTE 372)
• 1080p/50
• 2Kx1080p/50
3G-SDI Level A 2.967 (2.97/
1.001) Gb (SMPTE 425-A)
• 1080p/59.94 (SMPTE 274)
• 2Kx1080p/59.94
3G-SDI Level A 2.97 Gb
(SMPTE 425-A)
• 1080p/50 (SMPTE 274)
• 2Kx1080p/50
3G-SDI Level B 2.967 (2.97/
1.001) Gb (SMPTE 425-B /
SMPTE 372)
• 1080p/59.94 (SMPTE 274)
• 2Kx1080p/59.94
2.97 Gb 3G-SDI Level B
(SMPTE 425-B / SMPTE 372)
• 1080p/50 (SMPTE 274)
• 2Kx1080p/50
