HDMI The HDMI input only accepts SMPTE video formats, and accepts embedded audio. Video
input formats are RGB or YCbCr 4:2:2 pixel format for consumer video scan formats.
Computer scan rates are not supported.
• 525i/59.94. 525p/59.94
• 625i/50, 625p/50
• 720p/50/59.94
• 1080i/50/59.94
• 1080p/23.98/24/25/29.97/50/59.94
Component HD/SD
Analog
The Component Analog Input accepts YCbCr 4:2:2 pixel format, configurable to SMPTE or
Betacam levels. If the composite input is used, the component input is not available.
• 525i/59.94
• 625i/50
• 720p/50/59.94
• 1080i/59.94
• 1080PsF/23.98/24/25/29.97
• 1080p/23.98/24/25/29.97
Composite SD
Analog
The FS1-X composite analog video input/output formats are listed below. If the
component inputs are used, the composite input is not available.
• 525i/59.94 (switchable to NTSC 7.5 IRE or 0 IRE setup)
• 625i/50
Reference • 525i/59.94, 625i/50 analog composite
• 720p/50/59.94 tri-level sync
• 1080i/50/59.94 tri-level sync
• 1080p50 tri-level sync
• Genlock available to the current Video Processor 1 Input
• Free run
Video Format Conversion
Standard FS1-X Conversions The standard FS1-X can convert almost any input format to nearly any output format, as
long as the frame rates are of the same frame rate family. The three families are:
• 59.94/29.97/23.98
•50/25
•24
