• Delay: -128 to +12288 samples (-2.7 ms to +256 ms)
Interfaces
LAN • 10/100/1000 automatic configuration
• Automatic cable crossover (auto MDI-X)
• Embedded web server
•SNMP
GPI • DB-15F: single connector provides four inputs and four outputs. See Appendix B for a
connector pinout and GPI specifications.
Physical
Dimensions • Width: 17.5 inches (44.45cm); 19 inches (48.26 cm) including rack ears
• Depth: 16 inches (40.65 cm), including knobs and connectors that extend beyond the
frame
• Height: 1RU, 1.75 inches (4.44cm)
Weight • 7.85 pounds, 3.56 kilograms
Tem pe ratu re • Operating temperature range: 0–40 degrees C
• Cooled via two internal fans and side vents.
Power • Voltage: 100-240 VAC
• Power Consumption: 55 Watts, 60 Watts with FRC option (70 Watts maximum)
• Two independent power supplies, fully redundant, diode isolated.
