FS1-X v1.1 www.aja.com
20
• IP settings, MAC address
• SNMP settings
•Alarm control
• Hidden Menus, Screen Saver, and Display intensity
•Fan speed
• System serial number and software version
•System reboot
PRESET Displays the Reg Menu Group, which accesses the memory registers:
• Store, Recall, and edit the names of Presets
• Factory Preset (defaults)
SYSTEM Displays the System Menu Group, which lets you change or enable FS1-X video and
audio input and system functions:
• Video input format settings, including Analog and 3G setup
• Video component output format settings
• Analog audio standard levels
• Genlock reference source selection
• Output frame rate selection
• Frame Rate Converter option enable
• NTSC standard selection
• Composite video downconvert settings (HD to SD)
• HDMI RGB Range
• AES audio input format and sample rate conversion settings
VIDEO PROC Displays the Menu Groups that access Video Processor video input, format, and
conversion selections and adjustments:
Settings for both Video Processor 1 and 2:
•Input source selections
• Loss of input selection
• H and V timing and delay settings
• Freeze output setting
• Input scan format (pSF de-interlacer) settings
Setting for Video Processor 1 only:
• Output format and mode
• Background fill selection
• Conversion (up, down, aspect, edge, ROI, and custom settings)
• Matte adjustments
• Proc amp, color corrector, and legalizer settings
• Active Format Descriptor (AFD) settings
• Caption translation selection
• SD line 21 blanking selection
• Test pattern selection
VIDEO OUTPUT Displays the Output Menu Group, which selects which Video Processor output feeds the
various FS1-X output connectors:
