The Relay connection and setup is carried out via the Ajax Security System mobile app.
The built-in relay contacts are not galvanically connected to the device itself, so they can be connected to input
control circuits for different equipment, imitating a button, switch, etc.
Relay can be used to power various loads (sirens, water shut off valves, electromagnetic locks).
The miniature body of the device enables it to be installed inside a junction box, electric switchboard, or the cases of
switching units.
The device relay closes and opens the contact terminals on command via the Ajax Security System application. The
feasibility of automatic turning on/off of the Relay in response to the arming or disarming of the system has also been
implemented.
Relay operation modes:
• Bistable — the relay operates in the switch mode closing/opening contact terminals.
• Pulse —the relay closes/opens contact terminals for a specified period of time.
In the pulse mode, the Relay will close/open contact terminals for 0.5 to 15 seconds and then it will automatically perform the reverse action.
