AJAX Hub User Manual

Voltage protection
For 230 V mains: max — 253 V, min — 184 V
For 110 V mains: max — 126 V, min — 77 V
Maximum load current
13 А
Maximum current protection
Yes, 13 A
Power output (resistance load 230 V)
Up to 3 kW
Electricity meter function
Yes
Power consumption
parameters control
Yes: current, voltage,
consumed power
The power consumption of the device in the standby mode
Less than 1 W⋅h
Frequency band
868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the
region of sale
Compatibility
Operates only with Hub, Hub Plus, Hub 2 and ReX
Maximum RF output power
Up to 25 mW
Modulation
GFSK
Radio signal range
Up to 1,000 m (any obstacles absent)
Shell protection rating
IP20
Operating temperature range
From 0°С to +64°С
Maximum temperature protection
Yes, 65°C
Operating humidity
Up to 75%

AJAX Hub Specifications

General

Brand	AJAX
Model	Hub
Category	Switch
Language	English
