LED blinks for 4 seconds with an interval of 1 second, then
blinks 3 times rapidly (and automatically switches OFF).
The Module is deleted from the list of hub devices
LED blinks for 1 minute with an interval of 1 second, then
blinks 3 times rapidly (and automatically switches OFF).
The Module has received alarm/tamper signal
The LED lights up for 1 second.
Smoothly lights up and goes out when the detector or tamper is
activated.
Performance testing
The Ajax security system allows conducting tests for checking the functionality of connected devices.
The tests do not start straight away but within a period of 36 seconds when using the standard settings. The test time
start depends on the settings of the detector scanning period (the paragraph on “Jeweller” settings in hub settings).
Signal Strength Test
Attenuation Test
Connection of the Module to the wired detectorа
