AKAI DIGITAL DD8 Plus - Aes;Ebu Input;Output Connections

Page 105DD8 plus Version 2.20 - September 1998
AES/EBU INPUT/OUTPUT CONNECTIONS
PIN SIGNAL
2
8
7
6
5
4
3
1
9
PIN SIGNAL
11
17
16
15
14
13
12
10
18
PIN SIGNAL
20
25
24
23
22
21
19
13 1
25
14
D-Sub 25 Pin Female
AES/EBU INPUT/OUTPUT
Inputs 1/2 (Hot)
Inputs 3/4 (Hot)
Inputs 5/6 (Hot)
Inputs 7/8 (Hot)
Inputs 1/2 (Cold)
Inputs 3/4 (Cold)
Inputs 5/6 (Cold)
Inputs 7/8 (Cold)
Outputs 1/2 (Hot)
Outputs 3/4 (Hot)
Outputs 5/6 (Hot)
Outputs 7/8 (Hot)
Outputs 1/2 (Cold)
Outputs 3/4 (Cold)
Outputs 5/6 (Cold)
Outputs 7/8 (Cold)
Ground
Ground
Ground Ground
Ground
Ground
Ground
Not Used
Not Used
APPENDIX - 3
