A01 Access Control Admin Guide
AKUVOX SMART INTERCOM www.akuvox.com
Parameter Set-up:
Specific Port: select the specific ports from 1-65535 so that only the
data packet from the specific port can be captured. You can leave the
field blank by default.
PCAP: click Start tab and Stop tab to capture a certain range of data
packets before clicking Export tab to export the data packets to your
Local PC.
PCAP Auto Refresh Enabled: select Enable or Disable to turn on or turn
off the PCAP auto fresh function. If you set it as “Enable” then the PCAP
will continue to capture data packet even after the data packets reached
its 50M maximum in capacity. If you set it as Disable the PCAP will stop
data packet capturing when the data packet captured reached the
maximum capturing capacity of 1MB.
16. Firmware Upgrade
Firmware of different versions for A01 access control terminal can be
upgraded on the device web System > Upgrade interface.
