A03S Access Control Admin Guide
AKUVOX SMART INTERCOM www.akuvox.com
10. Relay Setting
You can configure the relay switch(es) for the door access on the web
interface.
10.1.1. Relay switch setting
To configure the configuration on web Hardware > Relay > Relay interface.
Parameter Set-up:
Trigger Delay (Sec): set the relay trigger delay timing (Ranging from 1-10
Sec.) For example, if you set the delay time as “5” sec. then the relay will
not be triggered until 5 seconds after you press “unlock” tab.
Hold Delay (Sec): set the relay hold delay timing (Ranging from 1-10 Sec.)
For example, if you set the hold delay time as “5” Sec. then the relay will
be delayed for 5 after the door is unlocked.
Relay Status: relay status is low by default which means normally closed
(NC) If the relay status is high, then it is in Normally Open status (NO).
Relay Name: name the relay switch according to your need. For example,
you can name the relay switch according to where the relay switch is
located for the convenience.
Note:
Only the external devices connected to the relay switch needs to be
powered by power adapters as relay switch does not supply power.
