1. First you need to open a browser (for example IE)
2. Input the IP address in the browser’s address bar and then press the Enter key
3. If successfully connected to IP phone, it will prompt a login page. In the page,
please input the username and password accordingly. By default, username and
password is as below:
User Name: admin
Password: admin
4. After successfully logged in, it will automatically locate to Status->Basic Page, as
figure shown below:
Sections Description
Product Information To display the device’s information such as Model name,
MAC address (IP device’s physical address), Firmware version
and Hardware firmware.
Network Information To display the device’s Networking status(LAN Port),such as
Port Type(which could be DHCP/Static/PPPoE), Link Status, IP
Address, Subnet Mask, Gateway, Primary DNS
