ALBIN PUMP ALH - Lubrication Table; Shoe Shimming Table

Albin Pump ALH Instruction Manual  Albinpump.com  albinpump@irco.com 47
since 1928
9.6 - HOSE RUPTURE AND VACUUM SYSTEM PARTS LIST (see specific exploded view)
ALH
Characteristics / Technical Specications
9.7 - LUBRICATION TABLE
The table indicates the quantity of lubricant necessary for every pump size. Employ only the ALBIN
lubricant for ALBIN hose pumps. refer to §6.2 for lubricant emptying and lling.
9.8 - SHOE SHIMMING TABLE
Refer to §6.5 to remove or add shims. The table below points out the necessary number of shims
under every shoe according to the speed, pressure and the temperature of the product. Respect these
indications scrupulously to optimize the hose life and to avoid a possible deterioration of the internal
parts. For temperatures exceeds 60°C (140°F), withdraw one shim in comparison with the table below.
For viscosities over 3000cP or concentrations exceeding 300g / l, withdraw one shim in comparison
with the table below. For a suction lift higher than 4 meters, add one shim to the following gures.
CAUTION: Every shoe must include the same number of shims 0.5mm (0.02 inch).
PUMPS ALH 5-10 ALH15-20 ALH25 ALH32 ALH40 ALHX40 ALH50 ALHX65 ALH65 ALHX80 ALH80 ALH100 ALH125
QUANTITY OF
LUBRICANT
0.2
(0.05)
0.55
(0.14)
2
(0.53)
3
(0.8)
3
(0.8)
6
(1.59)
13
(3.43)
16
(4.2)
13
(3.43)
27
(7.13)
40
(10.57)
80
(21.13)
120
(31.7)
PUMP TYPE ALH25
Pressure bar (psi) Speed - Rpm
Number of
shims
∆P ≤ 5 (72.5)
0 to 40 0
40 to 160 0
5 (72.5) ≤ ΔP ≤ 7.5 (108.75)
0 to 40 2
40 to 125 1
7.5 (108.75) ≤ ΔP ≤ 10 (145)
0 to 40 3
40 to 105 2
10 (145) ≤ ΔP ≤ 15 (217.5)
0 to 40 4
40 to 90 3
PUMP TYPE ALH40
Pressure bar (psi) Speed - Rpm
Number of
shims
ΔP ≤ 5 (72.5)
0 to 40 0
40 to 160 0
5 (72.5) ≤ ΔP ≤ 7.5 (108.75)
0 to 40 2
40 to 125 1
7.5 (108.75) ≤ ΔP ≤ 10 (145)
0 to 40 3
40 to 105 2
10 (145) ≤ ΔP ≤ 15 (217.5)
0 to 40 4
40 to 90 3
PUMP TYPE ALH32
Pressure bar (psi) Speed - Rpm
Number of
shims
ΔP ≤ 5 (72.5)
0 to 45 0
45 to 140 0
5 (72.5) ≤ ΔP ≤ 7.5 (108.75)
0 to 45 2
45 to 140 1
7.5 (108.75) ≤ ΔP ≤ 10 (145)
0 to 45 3
45 to 110 2
10 (145) ≤ ΔP ≤ 15 (217.5)
0 to 45 4
45 to 80 3
PUMP TYPE ALHX40
Pressure bar (psi) Speed - Rpm
Number of
shims
ΔP ≤ 5 (72.5)
0 to 40 0
40 to 120 0
5 (72.5) ≤ ΔP ≤ 7.5 (108.75)
0 to 40 2
40 to 95 1
7.5 (108.75) ≤ ΔP ≤ 10 (145)
0 to 40 3
40 to 75 2
10 (145) ≤ ΔP ≤ 15 (217.5)
0 to 40 4
40 to 60 3
LUBRICANT
L (gal)
