ALBIN PUMP ALH - ALHS Bearing Case Parts List; Hose Rupture and Vacuum System Parts List

46 albinpump@irco.com  Albinpump.com  Albin Pump ALH Instruction Manual
since 1928
ALH
Characteristics / Technical Specications
9.5 - ALH BEARING CASE PARTS LIST (see specific exploded view)
9.6 - HOSE RUPTURE AND VACUUM SYSTEM PARTS LIST (see specific exploded view)
REF. DESIGNATION
ALH 05
ALH10
ALH15
ALH20
ALH25 TO
ALH40
ALHX40
TO
ALH65
ALHX65 ALHX80 ALH80 ALH100 ALH125
101 BEARING CASE (ALHS) X X X X N/A X X X X
102 SHAFT (ALHS) X X X X N/A X X X X
103 ROLLER BEARING (ALHS) X X X X N/A X X X X
104 BALL BEARING (ALHS) X X X X N/A X X X X
105 LIP SEAL (ALHS) X X X X N/A X X X X
106 LIP SEAL (ALHS) X X X X N/A X X X X
107 CIRCLIPS (ALHS) X X X X N/A X X X X
108 GREASEER (ALHS) X X X X N/A X X X X
109 SHAFT KEY (ALHS) X X X X N/A X X X X
110 SHAFT KEY (ALHS) N/A X X X X
111 PLUG (ALHS) X X X X N/A X X X X
REF. DESIGNATION
CAPACITIVE HOSE
RUPTURE DETECTOR
PRESSURE GAUGE
HOSE RUPTURE
DETECTOR
AUTOMATIC AIR
VACUUM SYSTEM
AIR OPERATED
VACUUM SYSTEM
51 90° BEND X X X X
52 VENT X X X
200 HEXAGON NIPPLE X X X
201 TEE CONNECTION X X
202 HEXAGON NIPPLE X X
203 ADAPTOR X X X X
204 AIR SUPPLY CHECK VALVE X
205 AIR SUPPLY CONNECTION X
206 AIR SUPPLY HOSE X
207 VACUUM FLANGE X
