9.4 - ALH PUMP PARTS LIST (see specific exploded view)
REF. DESIGNATION ALHX40 ALH50 ALH65 ALHX65 ALHX80 ALH80 ALH100 ALH125
26 SHAFT SEAL ALHSH6080 SH-7085-ASP-15 SH-7085-ASP-15 ALHSH100S8 SH-100130-ASP-15 SH-100130-ASP-15 SH-110130-ASP-15 SH-130150-ASP-15
27 SEAL RING ALHSE5060 ALHSE6070 ALHSE6070 ALHSE90100 ALHSE90100 ALHSE90100 ALHSE100110 ALHSE12013030
28 SHOE BOLT SC1650HZN SC2060HZN SC2060HZN SC2080HZN SC2075HZN SC2090HZN SC20110HZN SC24110HZN
29 SHOE BOLT WASHER WAMW16ZN WAMW20ZN WAMW20ZN WAMW20ZN WAMW20ZN WAMW20ZN WAMW20ZN WAMW24ZN
30 SHOE CENTERING PIN ALHST0820 ALHST1025 ALHST1025 ALHST1025 ALHST1025
31 BOLT ON PLATE SCREW SC1660CST129 SC1660CST129 SC1660CST129
32 NUT FOR REF 31 NU16NYSS NU16NYSS NU16NYSS
33 COVER BOLT SC1220CSS SC1630CSS SC1630CSS SC1630CSS SC1630CSS SC1630CSS SC1630CSS SC2040CSS
34 COVER BOLT WASHER WAM12ZSS WAM16MSS WAM16MSS WAM16ZSS WAM16ZSS WAM16ZSS WAM16ZSS WAM20ZSS
35 COVER STUD 23500110 23500210 23500210 23500210 23500210 23500210 23500210 23500310
36 NUT FOR REF 35 NU12NYSS NU16NYSS NU16NYSS NU16NYSS NU16NYSS NU16NYSS NU16NYSS ALHNU20NY
37 SIGHT GLASS BOLT SC0620CSS SC0620CSS SC0620CSS SC0620CSS SC0620CSS SC0620CSS SC0620CSS SC0620CSS
38 WASHER FOR REF 37 WAM06ZSS WAM06ZSS WAM06ZSS WAM06ZSS WAM06ZSS WAM06ZSS WAM06ZSS WAM06ZSS
39 FRAME BOLT SC1225HSS SC1630HSS SC1630HSS SC2030HSS SC2030HSS
SC2030HSS SC2440HSS SC2440HSS
40 WASHER FOR REF 39 WAM12ZSS WAM16ZSS WAM16ZSS WAM20ZSS WAM20ZSS WAM20ZSS WAM24ZSS WAM24MSS
41 GEARBOX STUD GUD939M1235-304 GUD939M1240 GUD939M1240 GUD939M1650 GUD939M1650 GUD939M1650 GUD939M1650 GUD939M1650
42 NUT FOR REF 41 NU12NYSS NU12NYZN NU12NYZN NU16NYSS NU16NYSS NU16NYZN NU16NYZN NU16NYZN
43 SEAL FLANGE BOLT SC1016CSS SC1016CSS SC1016CSS SC1016CSS SC1016CSS
46 SIGHT GLASS SEAL ALHX404600 ALH654600 ALH654600 ALH804600 ALH804600 ALH804600 ALH1004600 ALH1004600
47 INLET & OULET FLANGE DIN ALH404700 ALH504700 ALH654700 ALH654700 ALH804700 ALH804700 ALH1004700 ALH1254701
47 INLET & OULET FLANGE ANSI ALH404720 ALH504720 ALH654720 ALH654720 ALH804720 ALH804720 ALH1004720 ALH1254720
48 BRACKET BOLT SC1016CSS SC1220CSS SC1220CSS SC1220CSS SC1220CSS SC1620CSS SC162(CSS SC2030CSS
49 BRACKET BOLT WASHER
51 90° BEND ALHBEMF34SS ALHBEMF1SS ALHBEMF1SS ALHBEMF112SS ALHBEMF112SS ALHBEMF112SS ALHBEMF112SS ALHBEMF112SS
52 BREATHER PLUG ALHPV34 ALHPV1 ALHPV1 ALHPV112 ALHPV112 ALHPV112 ALHPV112 ALHPV112
59 WHEEL BOLT WASHER ALH1005900 ALH1255900
60 WHEEL BOLT SC2470HSS SC2450HSS
63 LIFT RING ON COVER ALHX806301-00-00 ALHEYCO1 ALHEYCO1 ALHEYCO1
64 BOLT FOR REF 63 SC1620CSS SC1620CSS SC1620CSS SC1620CSS
67 O RING FOR SEAL FLANGE ALHCO03450 ALHCO03450 ALHCO03450 ALHCO03450 ALHCO03745
70 GEARBOX CENTRING FLANGE ALH807000
71
COVER FLANGE
72 WASHER for REF 41 WAM12ZSS WAM12ZSS WAM12ZSS WAM16ZSS WAM16ZSS WAM16ZSS WAM16ZSS WAM16ZSS
73 SPACER RING ALH050R060.06 ALH050R060.06 ALHX80SR090.13 ALHX80SR090.13 ALHX80SR090.13 ALH100SR100.33 ALH125SR120.07
74 PLUG ALHPL34GSS ALHPL1GSS ALHPL1GSS ALHPL112GSS ALHPL112GSS ALHPL112GSS ALHPL112GSS ALHPL112GSS
75 O-RING FOR 73 ALHCO03370
76 SPACER RING (ALH125 ONLY) ALH125SR120.18
77 WASHER FOR 59 ASK ALBIN ASK ALBIN
78 WASHER FOR LIFT RING 63 ASK ALBIN ASK ALBIN ASK ALBIN
79 NUT ASK ALBIN
80 WASHER ASK ALBIN
81 GUDGEON ASK ALBIN
82 SILENT BLOC ASK ALBIN
83 WASHER ASK ALBIN
84 NUT ASK ALBIN
