ALBIN PUMP ALH - Page 44

44 albinpump@irco.com  Albinpump.com  Albin Pump ALH Instruction Manual
since 1928
9.4 - ALH PUMP PARTS LIST (see specific exploded view)
ALH
Characteristics / Technical Specications
REF. DESIGNATION
ALH 05
(3 LOBES)
ALH10
ALH10
(3 LOBES)
ALH15
ALH15
(3 LOBES)
ALH20
ALH20
(3 LOBES)
ALH25 ALH32 ALH40
52 BREATHER PLUG ALHPV12 ALHPV12 ALHPV12 ALHPV12 ALHPV12 ALHPV12 ALHPV12 ALHPV12 ALHPV34 ALHPV34
59 WHEEL BOLT WASHER
60 WHEEL BOLT
63 LIFT RING ON COVER
64 BOLT for REF 63
67 O RING FOR SEAL FLANGE
70 GEARBOX CENTRING FLANGE
71 COVER FLANGE ALH107101 ALH107101 ALH107101 ALH157103 ALH157103 ALH157103 ALH157103
72 WASHER for REF 41 WAM08ZSS WAM08ZSS WAM08ZSS WAM08ZSS WAM08ZSS WAM08ZSS WAM08ZSS WAM10ZSS WAM12ZSS WAM12ZSS
73 SPACER RING
74 PLUG ALHPL12GSS ALHPL34GSS ALHPL34GSS
75 O-RING FOR 73
76 SPACER RING (ALH125 ONLY)
77 WASHER FOR 59
78 WASHER FOR LIFT RING 63
79 NUT
80 WASHER
81 GUDGEON
82 SILENT BLOC
83 WASHER
84 NUT
REF. DESIGNATION ALHX40 ALH50 ALH65 ALHX65 ALHX80 ALH80 ALH100 ALH125
1 CASING ALHX400117-00-00 ALH650117-00-STD ALH650117-00-STD ALHX800111 ALHX800111 ALH800110 ALH1000110 ALH1250110
2 COVER ALHX400211 ALH650211 ALH650211 ALHX800200 ALHX800200 ALH800210 ALH1000211 ALH1250210
3 WHEEL ALHX400310 ALH650310 ALH650310 ALHX800311 ALHX800311 ALH800310 ALH1000310 ALH1250310
4 SHIM ALHX400400 ALH650400 ALH650400 ALHX800400 ALHX800400 ALH800400 ALH1000400 ALH1250400
5 SHOE CAST IRON ALHX400530 ALH500530 ALH650530 ALHX650500 ALHX800540 ALH800530 ALH1000540 ALH1250530
5 SHOE PPH
6 SLEEVE ALHX400600 ALH500600 ALH650600 ALHX650600 ALHX800600 ALH800600 ALH1000600 ALH1250600
7 CLAMP SLEEVE ALHCL7090 ALHCL100120 ALHCL100120 ALHCL120140 ALHCL120140 ALHCL150170 - -
8 CLAMP ON SLEEVE / HOSE ALHCL7479 ALHCL8691 ALHCL9297 ALHCL100120 ALHCL122130 ALHCL122130 ALHCL162174 ALHCL175187
9 CLAMP ON HOSE ALHSL72 ALHSL94 ALHSL94 ALHSL400 ALHSL115 ALHSL145 ALHSL145 ALHSL675
10 COVER SEAL ALHCO61620 ALHCO62048 ALHCO62048 ALHCO62720 ALHCO62720 ALHCO63235 ALHCO63800 ALHCO64800
12 INSERT SS ALHX401200 ALH501200 ALH651200 ALHX651200 ALH801200 ALH801200 ALH1001200 ALH1251200
12 INSERT PPH ALHX401210 ALH501210 ALH651210 ALHX651210 ALH801210 ALH801210 ALH1001210 ALH1251210
12 INSERT PVDF
ALHX401220 ALH501220 ALH651220 ALHX651220 ALH801220 ALH801220
14 LUBRICANT
REF. TO LUBRI-
CANT QTY
REF. TO LUBRICANT
QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
15 SIGHT GLASS ALHX401500 ALH651500 ALH651500 ALH801500 ALH801500 ALH801500 ALH1001500 ALH1001500
16 HOSE
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
18 BRACKET GALV CS
18 BRACKET SS
18 ANSI/DIN BRACKET GALV CS ALHX401801-00-LG ALH501801-00-LG ALH651801-00-LG ALHX801801-00-LG ALH801801-00-LG ALH1001801-00-LG ALH1251801-00-LG
18 ANSI/DIN BRACKET SS 304 ALHX401802-00-LG ALH501802-00-LG ALH651802-00-LG ALHX651802-01-LG ALHX801802-00-LG ALH801802-00-LG ALH1001802-00-LG ALH1251802-00-LG
18 ANSI/DIN BRACKET SS 316 ALH801820
19 HUB ALHHU5080 ALHHU6090 ALHHU6090 ALHHU353590 ALHHU353590 ALHHU353590
20 BOLT ON PLATE ALHBO1990 ALHBO1990 ALHBO1990
21 FRAME CS L
21 FRAME CS R
21 FRAME SS L
21 FRAME SS R
21 COMPLETE FRAME ALHX402100 ALH652100 ALH652100 ALHX802100 ALHX802100 ALH802100 ALH1002100 ALH1252110
22 LIFT RING ALHEYM12 ALHEYM16ZN ALHEYM16ZN ALHEYM20 ALHEYM20 ALHEYM20 ALHEYM24ZN ALHEYM24ZN
23 OIL PLUG ALHPL34GSS ALHPL1GSS ALHPL1GSS ALHPL1GSS ALHPL1GSS ALHPL1GSS
ALHPL1GSS ALHPL112GSS
24 CIRCLIPS
25 SEAL FLANGE ALH802501-00-00 ALH802501-00-00 ALH802501-00-00 ALH802501-00-00 ALH1252501-BA120
