ALBIN PUMP ALH - ALH Spare Parts List

Albin Pump ALH Instruction Manual  Albinpump.com  albinpump@irco.com 43
since 1928
ALH
Characteristics / Technical Specications
9.4 - ALH PUMP PARTS LIST (see specific exploded view)
REF. DESIGNATION
ALH 05
(3 LOBES)
ALH10
ALH10
(3 LOBES)
ALH15
ALH15
(3 LOBES)
ALH20
ALH20
(3 LOBES)
ALH25 ALH32 ALH40
1 CASING ALH100110 ALH100110 ALH100110 ALH150110 ALH150110 ALH150110 ALH150110 ALH250110 ALH320110 ALH320110
2 COVER ALH100200 ALH100200 ALH100200 ALH150201 ALH150201 ALH150201 ALH150201 ALH250200 ALH320200 ALH320200
3 WHEEL ALH050310 ALH100310 ALH100303 ALH150310 ALH150330 ALH200310 ALH200340 ALH250310 ALH320310 ALH320310
4 SHIM ALH250400 ALH320400 ALH320400
5 SHOE CAST IRON ALH250530 ALH320530 ALH400530
5 SHOE PPH ALH250540 ALH320550 ALH400550
6 SLEEVE ALH100600 ALH100600 ALH100600 ALH150600 ALH150600 ALH150600 ALH150600 ALH250600 ALH320600 ALH320600
7 CLAMP SLEEVE ALHCL3250 ALHCL3250 ALHCL3250 ALHCL5070 ALHCL5070 ALHCL5070 ALHCL5070 ALHCL7090 ALHCL7090 ALHCL7090
8 CLAMP ON SLEEVE / HOSE ALHCL3639 ALHCL3639 ALHCL3639 ALHCL4043 ALHCL4043 ALHCL4043 ALHCL4043 ALHCL6063 ALHCL6873 ALHCL6873
9 CLAMP ON HOSE ALHCL3235 ALHCL3235 ALHCL3235 ALHCL3639 ALHCL3639 ALHCL3639 ALHCL3639 ALHSL60 ALHSL60 ALHSL60
10 COVER SEAL ALHCO03485 ALHCO03485 ALHCO03485 ALHCO3.5780 ALHCO3.5780 ALHCO3.5780 ALHCO3.5780 ALHCO61050 ALHCO61335 ALHCO61335
12 INSERT SS ALH051203-00-16 ALH101203-00-16 ALH101203-00-16 ALH151203-00-20 ALH151203-00-20
ALH201203-00-25 ALH201203-00-25 ALH251200 ALH321200 ALH401200
12 INSERT PPH ALH051204-00-16 ALH101204-00-16 ALH101204-00-16 ALH151204-00-20 ALH151204-00-20 ALH201204-00-25 ALH201204-00-25 ALH251210 ALH321210 ALH401210
12 INSERT PVDF ALH051218-00-16 ALH101218-00-16 ALH101218-00-16 ALH151218-00-20 ALH151218-00-20 ALH201218-00-25 ALH201218-00-25 ALH251220 ALH321220 ALH401220
14 LUBRICANT
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRICANT
QTY
REF. TO LUBRICANT
QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
REF. TO LUBRI-
CANT QTY
15 SIGHT GLASS ALH251500 ALH321500 ALH321500
16 HOSE
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
REFER TO HOSE
MATERIAL
18 BRACKET GALV CS ALH101801 ALH101801 ALH101801 ALH151801 ALH151801 ALH201801 ALH201801
18 BRACKET SS ALH101800 ALH101800 ALH101800 ALH151800 ALH151800 ALH201800 ALH201800
18 ANSI/DIN BRACKET GALV CS ALH251801-00-LG ALH321801-00-LG ALH401801-00-LG
18 ANSI/DIN BRACKET SS 304 ALH251802-00-LG ALH321802-00-LG ALH401802-00-LG
18 ANSI/DIN BRACKET SS 316 ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND
19 HUB ALHHU2550 ALHHU2550 ALHHU2550 ALHHU2550 ALHHU2550 ALHHU2550 ALHHU2550 ALHHU4065 ALHHU4065
ALHHU4065
20 BOLT ON PLATE
21 FRAME CS L ALH102101L ALH102101L ALH102101L ALH152101L ALH152101L ALH152101L ALH152101L ALH252100L ALH322100L ALH322100L
21 FRAME CS R ALH102101R ALH102101R ALH102101R ALH152101R ALH152101R ALH152101R ALH152101R ALH252100R ALH322100R ALH322100R
21 FRAME SS L ALH102100L ALH102100L ALH102100L ALH152100L ALH152100L ALH152100L ALH152100L ALH252100L ALH322100L ALH322100L
21 FRAME SS R ALH102100R ALH102100R ALH102100R ALH152100R ALH152100R ALH152100R ALH152100R ALH252100R ALH322100R ALH322100R
21 COMPLETE FRAME
22 LIFT RING
23 OIL PLUG ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL12GSS ALHPL34GSS ALHPL34GSS
24 CIRCLIPS ALH102400 ALH102400 ALH102400 ALH152400 ALH152400 ALH202400 ALH202400
25 SEAL FLANGE
26 SHAFT SEAL ALHSH3062 ALHSH3062 ALHSH3062 ALHSH3062 ALHSH3062 ALHSH3062 ALHSH3062 ALHSH4560 ALHSH4580 ALHSH4580
27 SEAL RING ALHSE2530 ALHSE2530 ALHSE2530 ALHSE2530 ALHSE2530 ALHSE2530 ALHSE2530 ALHSE4045 ALHSE4045 ALHSE4045
28 SHOE BOLT SC1030HSS SC1235HSS SC1235HSS
29 SHOE BOLT WASHER WAMW10ZN WAMW12ZN WAMW12ZN
30 SHOE CENTERING PIN ALHST0820 ALHST0820 ALHST0820
31 BOLT ON PLATE SCREW
32 NUT FOR REF 31
33 COVER BOLT SC0820CSS SC0820CSS SC0820CSS SC0820CSS SC0820CSS SC0820CSS SC0820CSS SC1020CSS SC1225CSS SC1225CSS
34
COVER BOLT WASHER
35 COVER STUD
36 NUT FOR REF 35
37 SIGHT GLASS BOLT SC0620CSS SC0620CSS SC0620CSS
38 WASHER FOR REF 37 WAM06ZSS WAM06ZSS WAM06ZSS
39 FRAME BOLT SC0816CSS SC0816CSS SC0816CSS SC0816CSS SC0816CSS SC0816CSS SC0816CSS SC1020CSS SC1220CSS SC1220CSS
40 WASHER FOR REF 39
41 GEARBOX STUD GUD939M0825 GUD939M0825 GUD939M0825 GUD939M0825 GUD939M0825 GUD939M0825 GUD939M0825 GUD939M1030 GUD939M1235-304 GUD939M1235-304
42 NUT FOR REF 41 NU08NYZN NU08NYZN NU08NYZN NU08NYZN NU08NYZN NU08NYZN NU08NYZN NU10NYZN NU12NYSS NU12NYSS
43 SEAL FLANGE BOLT
46 SIGHT GLASS SEAL ALH254600 ALH324600 ALH324600
47 INLET & OULET FLANGE DIN ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ALH254700 ALH324700 ALH404700
47 INLET & OULET FLANGE ANSI ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND ALH254720 ALH324720 ALH404720
48 BRACKET BOLT SC0612CSS SC0612CSS SC0612CSS SC0612CSS SC0612CSS SC0612CSS SC0612CSS SC0816CSS SC1016CSS SC1016CSS
49 BRACKET BOLT WASHER
51 90° BEND ALHBEMF12SS ALHBEMF12SS ALHBEMF12SS ALHBEMF12SS ALHBEMF12SS ALHBEMF34SS ALHBEMF34SS
