Description
3.4 - HOSE
The ALBIN hoses are manufactured according to very strict specications to acquire the best performances of the pump and to
assure an optimum hose life. They are available in six materials: Natural Rubber (NR), perbunan (NBR), EPDM, NBR food, Viton®,
and Hypalon®. The material of the hose must be compatible with the pumped liquid. Consult an ALBIN PUMP distributor to dene
the best hose for your process or consult the chemical resistance table on our website albinpump.com.
HOSE DIMENSIONS
mm (Inch)
PUMP Ø INSIDE THICKNESS LENGTH
ALH05 5 (0.2) 13.5 (0.5) 570 (22.4)
ALH10 10 (0.4) 11 (0.4) 570 (22.4)
ALH15 15 (0.6) 11 (0.4) 830 (32.7)
ALH20 20 (0.8) 9 (0.3) 830 (32.7)
ALH25 25 (1) 14.5 (0.6) 1090 (42.9)
ALH32 32 (1.2) 15.5 (0.6) 1300 (51.2)
ALH40 38 (1.5) 13.5 (0.5) 1300 (51.2)
ALHX40 40 (1.6) 13.5 (0.5) 1500 (59.1)
ALH50 51 (2) 15 (0.6) 1820 (71.7)
ALH65 60 (2.4) 13.5 (0.5) 1850 (72.8)
ALHX65 65 (2.5) 17.5 (0.7) 2075 (81.6)
ALHX80 80 (3.1) 17.5 (0.7) 2400 (94.5)
ALH80 80 (3.1) 21.5 (0.8) 2910 (114.5)
ALH100 100 (3.9) 22 (0.9) 3410 (134.2)
ALH125 125 (4.9) 21.25 (0.8) 4000 (157.4)
3.5 - GEAR BOX
Our standard gearboxes are coaxial gearboxes for pumps ALH05 to ALHX40 and planetary for pumps ALH50 to ALH100. ALH125
can be equipped with both. They have been sized according to the important radial loads of the pump. Consult the gearbox
maintenance manual provided with the pump to know the quantity of lubricant requested as well as the periodicity of oil change.
3.6 - ELECTRICAL MOTORS
The standard motors provided on our pumps are squirrel-cage motors and have a 230/400 V and 400/690 V 50/60 Hz three-phase
voltage. Voltage is dependent on the selected power supply. If the pump has to work in a potentially explosive environment, please
refer to the complementary information on ATEX compliances and contact your ALBIN PUMP distributor.
3.7 - AVAILABLE OPTIONS
ALBIN PUMP oers several options for their pumps:
- Hose rupture detector.
- Revolution-counter.
- Pulsation dampener.
- Air vacuum assistance (for highly viscous liquids).
- Variable speed drive.
- Mechanical variator.
Please contact your ALBIN PUMP distributor for any information about these dierent options .
