User Manual
Product information and planning
9500 MPR Rel. 3.1
3DB18809AAAA Issue 1198/980
ATM PW flows classification
ATM PW flows will be assigned to radio queues according to below table:
Scheduler
HQP scheduler algorithm will be used on Q8, Q7 and Q6.
Deficit Weighted Round Robin (DWRR) algorithm will be used for the other five queues.
By default, the DWRR algorithm is used with the following weights:
2.8.20.3 QoS in the MPT-HC/MPT-MC
The Radio QoS is implemented by MPT-HC/MPT-MC itself (not in the MPT Access unit).
The set of MPT Radio QoS features is the same of the one specified for the Modem unit (refer to par.
2.8.20.2) with the exception of the ATM CBR and UBR+ CoS: in MPT-HC/PT-MC they are sent to queue
#5 and queue #4 respectively (and not to queue #7 and queue #6).
ATM PW CoS Radio Queue
Guaranteed (CBR) Q7 (higher priority)
Best Effort (UBR+) Q6
BackGround (UBR) Q1
Queue Weight
Q5 (higher priority) 16
Q4 8
Q3 4
Q2 2
Q1 1
