Alcatel-Lucent 9500 MPR - Mpt-Hc;Mpt-Hc V2

User Manual
Product information and planning
9500 MPR Rel. 3.1
3DB18809AAAA Issue 188/980
2.6.3 MPT-HC/MPT-HC V2
2.6.3.1 6 to 13 GHz
2.6.3.2 15 to 38 GHz
L6 GHz U6 GHz 7 GHz 8 GHz 11 GHz 13 GHz
System
Frequency Range, GHz 5.925 -
6.425
6.425 -
7.11
7.125 -
7.9
7.725 -
8.5
10.7 -
11.7
12.75 -
13.25
T-R Spacings supported MHz 252.04 340 154,
161,
168,
196, 245
119; 126;
151.614;
208;
213,5;
266;
294;
305;
311.32
490-
500-530
266
Antenna Interface
Waveguide Type WR137 WR137 WR112 WR113 WR75 WR62
Typical power consumption (MPT-HC) 38 W
Guaranteed power consumption (MPT-HC) 40 W
Typical power consumption (MPT-HC V2) 37 W
Guaranteed power consumption (MPT-HC V2) 39 W
Typical power consumption (MPT-HC V2 with
RPS module)
38 W
Guaranteed power consumption (MPT-HC V2
with RPS module)
40 W
Typical power consumption (MPT-HC V2 with
XPIC-RPS module)
45 W
Guaranteed power consumption (MPT-HC V2
with XPIC-RPS module)
47 W
15 GHz 18 GHz 23 GHz 26 GHz 38 GHz
System
Frequency Range, GHz 14.4 -
15.35
17.7 -
19.7
21.2 -
23.632
24.52 -
26.483
37.0 -
39.46
T-R Spacings supported MHz 308-315-
322, 420,
490, 644,
728
1008-
1010,
1560, 340
1008,
1050-
1200-
1232
1008 1260
Antenna Interface
Waveguide Type WR62 WR42 WR42 WR42 WR28
