User Manual
Safety, EMC, EMF, ESD Norms and Equipment Label-
9500 MPR Rel. 3.1
3DB18809AAAA Issue 1 37/980
Moving Mechanical Parts: labeling and safety instructions
The following warning label is affixed next to fans or other moving mechanical parts:
Before carrying out any maintenance operation see that all the moving mechanical parts have been
stopped.
Equipment connection to earth
Terminals for equipment connection to earth , to be done according to international safety standards, are
pointed out by the suitable symbol:
The position of earth connection terminals is specified in the Hardware Installation section.
Heat-radiating Mechanical Parts: labeling and safety instructions
The presence of heat-radiating mechanical parts is indicated by the following warning label in compliancy
with IEC 417 Norm, Fig.5041:
DANGER! Possibility of personal injury:
Carefully observe the specific procedures for installation / turn-up and commissioning / maintenance of
equipment parts where heat-radiating mechanical parts are present, described in the relevant installation
/ turn-up and commissioning / maintenance documents and the following general rule:
Personal injury can be caused by heat. Avoid touching powered terminals with any exposed part of your
body.
