- Connect optional equipment
- Program keys
Prerequisites
None.
Connecting the sets
This section describes how to connect a set to the telephone system.
Prerequisites
None.
Connecting to the telephone system
To connect a set to the telephone system:
1. Turn the set over so that you can see its base.
2. Plug the RJ11 cable into the set's UA port/phone line connector.
3. Connect the RJ11 cable to a UA port in the telephone system.
Connecting optional equipment
This section describes how to:
- Connect an Add-On module (AOM) to the sets
- Connect a headset
- Connect an external hands-free device
Connecting an Add-On module to the sets
Add-On Modules (AOMs) can be connected to the Alcatel-Lucent 4029 Digital Phone and
Alcatel-Lucent 4039 Digital Phone sets. They are added to the right side of the set.
Three types of Add-On Module exist and provide keys associated with icons:
- AOM10 provides 10 keys
- AOM40 provides 40 keys
- AOM Alcatel-Lucent 8 series and Alcatel-Lucent 9 series Smart Display Module provides
14 keys with programmable LCD labels
Prerequisites
None.
Rules and restrictions
The following rules apply to the use of Add-On Modules with the Alcatel-Lucent 4029
Digital Phone and Alcatel-Lucent 4039 Digital Phone sets:
- A maximum of three Add-On Modules of the types AOM10 and AOM40 can be connected
to each set, providing up to 120 additional keys.
- A maximum of three Smart Display Modules can be connected to each set, providing up to
Chapter
4
()
4-72
