Server IP address and the SIP port must be set to value 5059
- Authentication Realm: Alcatel-Lucent OmniPCX Office Communication Server IP
address by default
- Registration interval: value greater than 120 seconds
- Transport protocol: the UDP protocol is preferred, TCP is used if the SIP packet length is
greater than the MTU value or if the remote SIP endpoint requests the TCP protocol
- Domain name: Alcatel-Lucent OmniPCX Office Communication Server IP address by
default
Displaying SIP Connection Current Status
As of R9.0, this feature allows the display of SIP connection status.
To display SIP connection status:
1. In OMC, go to Users/Base stations List > Details.
2. Read the SIP connection status (under the terminal's physical status).
The following table lists the different displayed status.
Displayed Status Meaning
Set not connected SIP phone disconnected from network / No
SIP registration request from the phone
SIP registration KO SIP registration request from SIP Phone
rejected by Alcatel-Lucent OmniPCX Office
Communication Server
Set unregistered SIP phone unregistered from Alcatel-Lucent
OmniPCX Office Communication Server
SIP registration OK SIP phone connected and successfully
registered to Alcatel-Lucent OmniPCX Office
Communication Server
4.5 8 Series Sets
4.5.1 IP Touch 4008/4018 Phone
4.5.1.1 Commissioning
4.5.1.1.1 Overview
This module presents all the actions required for commissioning:
- The Alcatel-Lucent IP Touch 4018 Phone set
- The Alcatel-Lucent IP Touch 4018 phone Extended Edition set
The commissioning of Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent IP Touch 4018
phone Extended Edition sets is identical.
The following figure illustrates the connectors on the base of the Alcatel-Lucent IP Touch
4018 Phone and Alcatel-Lucent IP Touch 4018 phone Extended Edition sets.
()
4-57
