4.4.4 Generic SIP Phones
4.4.4.1 Commissioning
4.4.4.1.1 Overview
This module presents all the actions required for commissioning generic SIP sets.
The List of supported SIP Phones is available on the Alcatel-Lucent Applications Partner
Program (AAPP) web site.
4.4.4.1.2 Commissioning Generic SIP Sets
This section describes how to commission a generic SIP Set.
The following operations must be performed:
1. Configure the user in OMC, refer to Configuring the User in OMC
2. Connect the set, refer to Connecting the Set and switch it on
3. Configure the generic SIP set, refer to Configuring the generic SIP set
Prerequisites
- The Alcatel-Lucent OmniPCX Office Communication Server must be R810 or higher and
must be operational
- A free IP address must be available for the set
- A port with PoE must be available on a switch
Configuring the User in OMC
To create a generic SIP set:
1. In OMC, go to Users/Base stations List.
2. Select a No., IP access and click on the Add button.
3. Select IP terminal and enter a Name.
4. Select the newly created user in the list and select Basic SIP Phone or Open SIP Phone
in the combo box.
See the different features relating to basic or open SIP modes: List of Services Provided -
Services provided - Services Offered on SIP Sets
5. Click the Modify button.
6. Click the Details button. The User window is opened.
7. Click the IP/SIP button. The IP/SIP parameters window is opened.
8. In the SIP parameters tab, click the SIP password reset button. A new password is
generated in the SIP password field.
9. A virtual MAC Address is automatically generated but it can be replaced by the real MAC
Address of the SIP device.
Note:
The MAC Address must be unique and is used to identify the subscriber in the OmniPCX Office call
handling (SIP password is used for authentication).
()
4-55
