Board Function Optional boards Connections
PowerMEX
(equipped with
an HSL1 board)
Extension module controller
MIX244
MIX248
MIX284
MIX484
MIX448
MIX044
MIX084
MIX048
0, 2 or 4 T0 basic accesses + 4
or 8 UA interfaces + 4 or 8 Z
interfaces
ISDN network, analog Z
terminals and Alcatel-Lucent
9 series or Alcatel Reflexes
stations
AMIX484-1
AMIX448–1
AMIX444–1
4 analog line accesses, 4 or 8
UA interfaces and 4 or 8 Z
interfaces
GSCLI: Ground Start
signaling
CLIDSP: local CLIP
management
METCLI
PSTN network, analog Z
terminals and Alcatel-Lucent
9 series or Alcatel Reflexes
stations
PRA-T2
PRA-T1
DASS2
DLT2
T1-CAS
T1-CSS
PCM R2
PRA -T2, DASS2, DLT2: 30 x
64-Kpbs B-channels + 1 x
64-Kbps D-channel; 2048 Kbps.
PRA-T1: 23 x 64-Kbps
B-channels + 1 x 64-Kbps
D-channel; 1544 Kbps
23 x 64-Kbps B-channels + 1 x
64-Kbps D-channel
T1-CAS: 24 x B-channels,
including signaling; 1544 Kbps.
PCM R2: 30 x 64 Kbps
B-channels +1 x 4 Kbps
signaling channel; 2048 Kbps.
PRA-T2: ISDN network
DASS2: UK public/private
network
DLT2: Private QSIG
network
PRA-T1: Hong-Kong ISDN
network
ISDN (US) T1-CAS: USA
public network
PCM R2: Public network
SLI4
SLI8
SLI16
SLI4-1
SLI8-1
SLI16-1
SLI4-2
SLI8-2
SLI16-2
4, 8 or 16 Z interfaces Analog Z terminals
UAI4
UAI8
UAI16
UAI16-1
4, 8 or 16 UA interfaces
UAI16-1 board: possibility of
powering terminals connected to
the 16 interfaces remotely from
an external EPS48 power supply
Alcatel-Lucent 9 series or
Alcatel Reflexes stations
Multi Reflexes 4099
4070 IO/EO DECT base
stations
EPS48 only on interface 1
of the UAI16-1 board
