8 Not used
Power supply socket:
Pin Description
1 0V
2 40V DC
4.9.3.3 Power Supply Details
The interface module local power supply is required only when S0 terminals do not have their
own local supply.
The power supply unit depends on country:
Reference Characteristics Country
1AF00446CAAA 230V AC/42V DC 150mA Europe
1AF00446ABAA 127V AC/44V DC 150mA Brazil
1AF00446AGAA 220V AC/42V DC 150mA Argentina
1AF00446ASAA 240V AC/42V DC 150mA Australia
1AF00446AUAA 115V AC/42V DC 150mA USA
1AF00446BAAA 230V AC/42V DC 150mA UK
4.9.3.4 Environment
Working temperature: 5°C to 45°C
Stocking temperature: -40°C to 70°C
Relative humidity: 5% to 85%
4.10 Intelligent Base Stations
4.10.1 Detailed description
This notice describes the rules to follow for an installation comprising three or four DECT
bases.
For a larger installation, a preliminary study must be carried out using coverage tools. The
bases are then installed according to the results of this study.
4.10.1.1 CONNECTION
The Alcatel-Lucent 4070 IO is designed for internal installation in the building, while the
Alcatel-Lucent 4070 EO is designed for external installation.
The 4070 EO IBS comes in a plastic box and is protected against temperature variation.
The 2 antennae are outside the box so that they both have the same signal reception.
Intelligent Base Stations (IBS) are fitted with a red LED that gives information about the state
of the Base Station:
Chapter
4
()
4-90
