Alcatel-Lucent OmniPCX Office Installation Manual

For performance and safety reasons, the whole system must always be coupled
to the ground. The ground must be connected before any other connections.
The ground protection connection terminal must always be connected to the
ground. Protective grounding terminal shall be permanently connected to the ground.
4.3.1.5.2 OmniPCX Office RCE Compact
OmniPCX Office RCE Compact platform is powered by an external power supply unit
(100/240V). It is connected via a jack plug at the front of the module (right hand side).
Remarks:
- A mains cable is not supplied with the module. It must be ordered separately.
- For a more secure configuration, an AC/DC power supply, including a backup battery, can be
purchased as an optional extra.
Permanent Ground
It is essential to connect the system permanently to ground due to leakage currents greater
than 3.5 mA over the whole line access (safety constraint CEI60950 ed.03).
To do this, use the ground wire of minimum section 2.5 mm
2
(not supplied) and connect it to
the tag on the metal bottom of the unit (right hand side).
For performance and safety reasons, the system must always be connected to the
ground. The ground must be connected prior to all the other connections.
For performance and safety reasons, the whole system must always be coupled
to the ground. The ground must be connected before any other connections.
The ground protection connection terminal must always be connected to the
ground. Protective grounding terminal shall be permanently connected to the ground.
4.3.1.6 Power Up
Having made all the connections, it is now time to power up the system.
- Insert the mains cable in the socket on the rear of the unit.
- Press the ON/OFF button. The system will reinitialize (duration: 3 to 4 minutes).
To stop the system:
- Press the ON/OFF button, the RED LED will flash.
- Wait until the LED stops flashing and is lit steadily (between 15 seconds and 3 minutes
depending on the configuration): the system is switched off.
4.3.1.6.1 Power Up of Dedicated Terminals
On powering up, dedicated sets execute a self-test:
- Display Test
- Test of the LEDs or icons on the terminal and add-on module, if any
  ()
          
4-33

Alcatel-Lucent OmniPCX Office Specifications

General

VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Humidity	10% to 90% non-condensing
Type	IP PBX
Maximum Trunks	Up to 60
Voice codecs	G.711, G.729
Network Interfaces	10/100 Ethernet
Weight	Varies depending on the model/configuration
