auto-negotiation mode
• IP parameters
• Log parameters, allowing to define a syslog server for log reception
• Network parameters, allowing to:
• Enable and configure a DHCP User Class: this makes the set send the standard
DHCP option 77 (User Class, RFC2132) within the DISCOVER and REQUEST
DHCP messages. Using this option allows to define groups of terminals, and to
attach these groups to different and independent Com Servers.
• Define an SNTP Server address and refresh period
• Proxy host and port
• SIP parameters (read only)
- In Security menu:
• 802.1x parameters
• Certificates: not used
Configuring the user name and password in OMC
To modify the name and reset the password:
- In OMC, go to Users/Base stations List.
- Click the user in the list, modify her/his name in the corresponding field and click Modify.
- In the SIP Parameters tab, click the SIP password reset button to get a new password (In
OMC, only reset of user password can be done, user password can be set only in 8082 My
IC Phone set).
Connecting optional equipment
Headsets
A headset can be used with 8082 My IC Phone sets.
By default the set is configured to detect headset connection. When the headset is plugged in,
the audio is sent to the headset. The hands-free key allows you to switch from handset to
headset.
A Bluetooth® headset may be used.
If your headset is wired, plug it to the associated set connector (see: figure: 8082 My IC Phone
set connectors ), which can be any of the following:
- The jack plug
- The set USB port
External station speakers
Any connector used for a headset can be used for external speakers.
Customize your set to take the external station speaker into account:
1. Touch the Settings button
Note:
According to system administration, this button may not appear. The availability of this option is
determined by the set configuration files. Contact your telephony and/or system administrator.
Chapter
4
()
4-44
